THz beam analyzer
Model：WinCamD-THz
Overview
Applications: nonlinear spectroscopy; Medical safety inspection / quality assurance of opaque items; On site maintenance of terahertz laser and laser system.Description
1. Overview
THZ光束分析仪 provided by Sunpump, designed for thz laser beam quality measurement applications. Customization is available upon request.
3. Typical Applications
THz laser beam quality measurement; nonlinear spectroscopy; THz system alignment; research applications.
Specifications
| wavelength coverage | 3 – 20 THz (15 to 100 μm) plus 350- 1150 nm |
Technical Data
Port-powered USB 3.0
Features
- 波长范围：3 – 20 THz (15 to 100 μm) plus 350- 1150 nm
- 像素：2048 x 2048 pixels, 11.3 x 11.3 mm active area
- 像素大小：5.5 µm pixels
- 帧数：12 fps @ 2048x2048 to 60 fps @ 512x512
- 接口：Port-powered, USB 3.0; flexible 3 m cable
- HyperCal™ – Dynamic noise and baseline correction software
- Real-time non-linearity correction
- Global electronic shutter, 85 µs to 2 s
- TTL, optical and auto-trigger options
- 12-bit ADC
- Parallel capture on multiple cameras
- Field-replaceable image sensors
- Relative power level display
